| Parameters |
| Model | Unit | LZ50/50/60/50/50-1700 | LZ50/55/65/65/55-2000 | LZ55/65/65/65/55-2400 |
| Material | | LDPE/LLDPE/mLLDPE/EVA |
| Layer | | 5 |
| Film Thickness | mm | 0.03-0.15 |
| Max Film Width | mm | 1500 | 1800 | 2200 |
| Max Output | Kg/hr | 200 | 260 | 400 |
| Screw Diameter | mm | Ф50Ф50Ф60Ф50Ф50 | Ф50Ф55Ф65Ф65Ф55 | 55Ф65Ф65Ф65Ф55 |
| Screw L/D | | 1:32 | 1:32 | 1:32 |
| Die Head Diameter | mm | Ф400 | Ф450 | Ф500 |
| Air Ring Lip Diameter | mm | Ф450 | Ф500 | Ф550 |
| Driving Motor Power | KW | 30/30/37/30/30 | 30/37/45/45/37 | 37/45/45/45/37 |
| IBC System | Germany B+R System |
| EPC System | EPC Auto Edge Position Control System |
| Filter Changer Type | Manual Quick Screen Changer |
| Rewind Type | Surface Winding/Surface·Center·Clearance Winding |
| Tension Control System | Auto |
| Dimension（L*W*H） | m | 12*8.5*11 | 12.5*8.5*11 | 12.5*8.5*11 |
|
 |
