  5 Layer Coextrusion Non-obstructive (Special For POD)Film Blowing machine
Parameters

Model UnitLZ50/50/60/50/50-1700LZ50/55/80/65/55-2000LZ55/65/65/65/55-2300
MaterialLLDPE/LDPE/HDPE/EVA/mLLDPE
Layer5
Film Thickness  mm0.03-0.15
Max Film Widthmm150018002100
Max OutputKg/hr200260300
Screw DiametermmФ50Ф50Ф60Ф50Ф50Ф50Ф55Ф80Ф65Ф55Ф55Ф65Ф65Ф65Ф55
Screw L/D1:321:321:32
Die Head DiametermmФ400Ф450Ф480
Air Ring Lip DiametermmФ450Ф500Ф530
Driving Motor PowerKW30/30/37/30/3030/37/75/45/3737/45/45/45/37
IBC SystemGermany B+R System
EPC SystemEPC Auto Edge Position Control System
Filter Changer TypeManual Quick Screen Changer
Rewind TypeSurface Winding/Surface·Center·Clearance Winding
Tension Control SystemAuto
Dimension(L*W*H)m12.5*8*1112.5*8.5*1112.5*8.5*11


Remarks



ADD:NORTH AREA ZHAOAN INDUSTRIAL ZONE,ZHANGZHOU CITY, FUJIAN PROVINCE.
